model no. :
Fast Speed UV Curing MachineBrand:
DSXUVport of dispatch :
SHENZHENPayment :
T/Toriginal region :
CHINALead Time :
15-30 DAYSPortable UV Coating Curing Machine for UV Varnish is instant drying, excellent coating performance. Particularly, afther cross-linking density, UV curing coating is much higher than the thermal drying coating.
Product Parameters of High Performance Instant Curing UV Coating Machine :
Type
UV Coating Drying Machine
Place of Origin
Guangdong, China (Mainland)
Brand Name
UV-LED CURING
Model Number
HYUV-4II
Wavelength
365nm/375nm/385nm/395nm/405nm/415nm
Irradiation Area
20*35mm
Cooling Method
Air Cooling or Water Cooling
No.
W20*100
W20*200
W20*350
Power Consumption(W)
300
550
950
Cooling Method
Water Cooled
Water Cooled
Water Cooled
Emitting Window Size(mm)
20*100
20*200
20*300
Dimension(nm)
138*42*28
238*42*28
388*42*28
Wavelength(nm)
395
395
395
UV Intensity(mW/cm2)
12000
12000
12000
Irradiation Distance(mm)
10-20
10-20
10-20
UV-LED CURING W20 Serious of Fast Speed LED UV Drying Machine for Label Printing :
W20 serious UV Coating Curing Equipment can be used for curing uv ink, uv varnish and uv paint. It fit to screen printer, flex printer and flexo printer.
W50 serious UV Coating Drying Machine can be used for high speed UV printing, it fit to high speed flex printer and offset printer.
For more about Low Temperature LED UV Light Curing Coating Technology, please contact : 1651063690jennifer@gmail.com (Jennifer)
Air Cooling UV Solidify Machine, Emitting Window:104*25mm, is designed as a simple, low cost, small form factor air-cooled UV LED curing lamp for pinning and curing of inks, coatings and adhesives, mobile phone touch screen.
The WnnexCureTM EB168 UV Light Emitting Diode provides highest output power in an extremely medium mechanical package for high speed pinning and full cure applications. The EB168 UV LED Light Source is CE, RoHS, and REACH compliant.
100*100mm high power top quality power saving 365nm LED UV Curing Machine Curing UV Glue can be customized. You know 365nm is the best wavelength to cure UV glue.
Customized 365nm UV LED Curing System for lens bonding. UV LED Area Curing System can make glue curing, wavelength 365nm, rec area : 20*25mm, quickly, effective to cure.
Energy Saving Bar Type LED UV Curing System, This kind of UV LED curing system can be used for curing UV ink, UV varnish and UV paint and is suitable for flex printer, offset printer, flatbed printer and flexo printer.
High Power UV LED Dryer for UV Adhesive Curing System is 30*120mm, 365nm.
