395nm LED UV Curing System Curing UV Paint always uses water cooling. The product is easy handling, applecable to a variety of base materials.
model no. :
395nm LED UV Curing SystemBrand:
DSXUVport of dispatch :
SHENZHENPayment :
T/Toriginal region :
CHINALead Time :
15-30 DAYS395nm Water Cooled UV LED Curing System Curing UV Paint is photoelectric induction, instant on/off, no preheating required. Also, it is Low energy consumption, just 20% of the ordinary UV lamp.
Product Parameters of 395nm Water Cooling LED UV Curing System:
Condition |
New |
Type |
UV curing machine |
Automatic Grade |
Automatic
|
Place of Origin |
Guangdong, China (Mainland) |
Brand Name |
UV-LED CURING |
Model Number |
UV-LED CURING-4 |
Voltage |
220V |
Power(W) |
10w~2000w |
Dimension(L*W*H) |
340*240*170mm |
Weight |
10kg |
Certification |
ISO |
Warranty |
1 Year |
After-sales Service Provided |
Engineers Available to Service Machinery Overseas |
Wavelength |
365nm~405nm |
Cooling Method |
Air Cooling or Water Cooling |
|
|
For more details about Professional UV LED Curing Technology, please contact : 1651063690jennifer@gmail.com (Jennifer)
Technical Data of Collimated UV LED Curing Equipment Controller:
Type
XYUV -4Ⅱ
Channel
1
The size of controller
L384*W284*H90mm
Terminal I/O
Input
Pedal switch & serial RS-232 communication signals
Output
Serial RS-232 communication signals
Cooling method of controller
Air cooling
Power supply voltage
AC100~240V±10%(50/60HZ)
Operation mode
Touch Panel
Ambient temperature and humidity
Ambient temperature: -10℃—50℃ Relative humidity: 25%—85%RH
Dimming/Exposure control
Digital Debugging, Manual exposure control, Foot control or timing control (0.1~9999s)
Setting operation
Using the operating switch is set, Power key parameter switch, RS-232
External Control
External input
Enter irradiation alone Irradiation stop input, Interlocking, All lights illuminated input, Query switch
External output
REDAY signal, Error signal, Warning Output, Busy output (Various skinhead), +5VOutput(indicator used)
Irradiation Head Specification of Hand-held UV Curing Lamp for 3D printing :
Model
UV-LED CURING S176-20X200-395
Setting Specification
700mA Constant Current
Electronic Power
1500W
Electric Power
Water Cooling
Control
XYUV-4ⅡController, Channel Alone Control
Curing Area
Length 20mm; Width:200mm
Irradiation Distance
10-15mm
UV LED Curing Head
Wavelength
395nm
Peak Irradiance
12W/cm2
Uniformity
±5~8%
Grade
No.1,3B Product
Air Cooling UV Solidify Machine, Emitting Window:104*25mm, is designed as a simple, low cost, small form factor air-cooled UV LED curing lamp for pinning and curing of inks, coatings and adhesives, mobile phone touch screen.
The WnnexCureTM EB168 UV Light Emitting Diode provides highest output power in an extremely medium mechanical package for high speed pinning and full cure applications. The EB168 UV LED Light Source is CE, RoHS, and REACH compliant.
100*100mm high power top quality power saving 365nm LED UV Curing Machine Curing UV Glue can be customized. You know 365nm is the best wavelength to cure UV glue.
Customized 365nm UV LED Curing System for lens bonding. UV LED Area Curing System can make glue curing, wavelength 365nm, rec area : 20*25mm, quickly, effective to cure.
Energy Saving Bar Type LED UV Curing System, This kind of UV LED curing system can be used for curing UV ink, UV varnish and UV paint and is suitable for flex printer, offset printer, flatbed printer and flexo printer.
High Power UV LED Dryer for UV Adhesive Curing System is 30*120mm, 365nm.
