High Intensity UV LED Curing Equipment can apply for Adhesive and Coating, Printing.
model no. :
Flexo Press UV LED Curing EquipmentBrand:
DSXUVport of dispatch :
SHENZHENPayment :
T/T 100% Before Shipmentoriginal region :
CHINAHigh Power UV LED Curing Equipment for UV Coating can apply for Adhesive and Coating. UV LED for Adhesive, Electronics ( Micro Speakers, LCD,LCM,Lens camera and etc), Medical Industrial, Flexo.Screen printing.offset printing and Narrow web printing etc. UV LED for Coating, Woodproducts, Automotive , Industrial etc, UV LED for Printing.
Quick Details of Industrial Specilized UV LED Curing System for Offset Printing :
Type |
UV Curing machine |
Automatic Grade |
Semi-Automatic |
Place of Origin |
Guangdong, China (Mainland) |
Brand Name |
DSX |
Model Number |
DSX-264*20*260 |
Voltage |
220V/50Hz |
Power(W) |
500W-1000w |
Weight |
12kg |
Certification |
CE Certificate, RoHS |
Warranty |
One Year |
After-sales Service Provided |
Overseas third-party support available |
Application |
letterpress label printer.flexo printing |
Wavelength |
395nm 405nm |
Technical data of Linear Type LED UV Curing Lamp for Flexo Printer :
product model |
eimitting window size |
wavelength |
cooling method |
peak irradiation |
irradiation distance |
UV-LED CURING-S264-20x260 |
20X260mm |
395nm |
water cooling |
14000mw/cm² |
5mm |
Advantages of Ultraviolet UV LED Curing Light for Printer Ink Curing :
Replace the mercury lamp!
Extra-long life: 25000h~30000h
Energy saving: save 80% electrical energy than Mercury lamp
Multiple control modes : Constant current, pedal control,intelligent optical and manual modes
Photoelectric induction, instant on/off, no preheating required.
No mercury, No Ozone, eco-friendly
Cold light source, low temperature
High Effeciency UV LED Curing Lamp, because of its extra-long life, energy saving, stable output, high uniformity,has been chosen by customers. And also, mulyiple control modes is one of its advantages.
Fan/Water cooling is used to High Power 395nm UV LED Curing Lamp. Because of cold light source, it does not produce harmful ultraviolet radiation without thermal radiation and reduce the heat generated by the curing process.
Professional and Effective UV LED Curing Dryer, the wavelength is 365~405nm, is not suitable for nails.
Air-Cooled UV LED Linear Light Souce is through professional designed optical lens module outputting a long and narrow UV LED light band, satisfying banding, printing and other production needs.
UV LED Linear Light Source Machine do not need to replace the ink, is power saving, high efficiency, practical, mercury free, etc..
Customized UV LED Linear Light Source System, its luminescent mode emits a linear light spot, is made of numbers of LED chips.
