8 inches Mercury Lamp UV Tape UV Curing Systems Reciprocating Conveyor Belt UV Curing Light Source 8 inches Mercury Lamp UV Tape UV Curing Systems Reciprocating Conveyor Belt UV Curing Light Source 8 inches Mercury Lamp UV Tape UV Curing Systems Reciprocating Conveyor Belt UV Curing Light Source 8 inches Mercury Lamp UV Tape UV Curing Systems Reciprocating Conveyor Belt UV Curing Light Source

8 inches Mercury Lamp UV Tape UV Curing Systems Reciprocating Conveyor Belt UV Curing Light Source

8 inch UV Tape Curing Systems reduce the adhesive strength of all UV-sensitive dicing tapes under controlled environment

  • model no. :

    UV Tape Curing Systems
  • Brand:

    DSXUV
  • port of dispatch :

    Shenzhen
  • Payment :

    T/T 100% before shipment
  • original region :

    China
Product Details

8 inch Wafer UV Light Curing Machine reduce the adhesive strength of all UV-sensitive dicing tapes under controlled environment.


Parameters:

Mode

DSXUV-DG-8

Glass

Quartz glass

Cooling

Air cooling

Irradiation

From top down

Luminous

Mercury lamp (full band)

Power

1-4KW

Lighting area

110*320mm

Intensity

UVA>200mW/cm2

Uniformity

90%

Mercury lamp

2KW*220V*L400mm

Voltage

220V

Operation mode

Motor drive (track slide scan)

Run number

Adjustable (touch screen)

Running speed

Adjustable (touch screen)


8 inch Blue Film UV Tape UV Curing Systems


Mercury Lamp UV Tape UV Curing System Characteristics:

1.Table type, chain drive

2.Adjustable time and brightness, touch screen operation, simple and convenient

3.Compatible, large size iron rings are compatible with small size

4.Uniformly reduce the viscosity of UV film

5.Fast curing in few seconds

6.Intuitive control panel

7.Enable time control process

8.Compact design

9.Compliance with the highest safety standards

10.Environmentally friendly


Application for UV Tape UV Curing Systems:

Suitable for semiconductor material like optical lens, LED, IC, semiconductor, integrated circuit board, mobile hard disk, etc., reducing UV film viscosity like glass filter, UV tape, blue film.
