High Power UV Curing System 395nm is for fast curing. It is without preheating, out-of-the-box, easy to handle.
model no. :
High Power 395nm Fast Curing SystemBrand:
DSXUVport of dispatch :
SHENZHENPayment :
T/Toriginal region :
CHINALead Time :
15-30 DAYS
Why do we chose the product of 395nm High Power UV Curing System for Fast Curing? The cause is clear. Our company pursue the product of high efficiency, practicability, environmental protection. As 395nm High Power UV Curing System for Fast Curing, it can be used without replacing the ink. Also, low temperature is most important for safely using.
Product Parameters of 395nm Fast UV LED Curing System:
Place of Origin
Guangdong, China(Mainland)
Brand Name
UV-LED CURING
Model Number
UV-LED CURING-SL
Rated Power
1600w
Voltage
220V
Wavelength
365nm/375nm/385nm/395nm/405nm/415nm
Technical Data of LED UV Curing System Controller :
Type
UV-LED CURING SL
Channel
2
The size of controller
L384*W350*H100mm
Terminal I/O
Input
Pedal switch & serial RS-232 communication signals
Output
Serial RS-232 communication signals
Cooling method of controller
Water cooling
Power supply voltage
AC100~240V±10%(50/60HZ)
Operation mode
Touch Panel
Ambient temperature and humidity
Ambient temperature: -10℃—50℃ Relative humidity: 25%—85%RH
Dimming/Exposure control
Digital Debugging, Manual exposure control, Foot control or timing control (0.1~9999s)
Setting operation
Using the operating switch is set, Power key parameter switch, RS-232
External Control
External input
Enter irradiation alone Irradiation stop input, Interlocking, All lights illuminated input, Query switch
External output
REDAY signal, Error signal, Warning Output, Busy output (Various skinhead), +5VOutput(indicator used)
Technical data of UV Curing Machine :
Product Model
Emitting Window Size
Wavelength
Cooling Method
Peak Irradiation
Irradiation Distance
UV-LED CURING
S528-30*350
30*350mm
395nm
Water Cooling
20000mw/cm2
10-20mm
Energy saving factory price UV LED Curing System with desktop conveyor for printing. Effective irradiated area: 30mm*200mmTotall size: 1500x300mm and 1200x400mm
Customized UV LED Dyrer UV Curing Machine with conveyor system.Chain conveyor belt can be adjustable width.Curing Area 300*200mm or other sizes available.
Desktop LED UV Dryer Machine for uv curing. PCB/PCBA Conformal Coating curing. SMT component protection and reinforcement. Medical instrument UV glue curing.
UV LED data line solder joint reinforcement curing machine, replacing traditional mercury lamp, built-in UVLED curing light source, low temperature, no ozone, no deep ultraviolet, low energy consumption and high efficiency.
UV LED Curing Machine for Label Printing is 1000W, for offset printing. It most used for machine facilities.
UV LED+ mercury lamp integrated curing machine, built-in UVLED curing light source and low-power mercury lamp, perfect solution to dry surface problems, simple operation, energy saving.
